SPECIFICATIONS

Brand Name: NONE

Certification: CE

Choice: yes

Encoding method: Fixed code

High-concerned chemical: None

Origin: Mainland China

Product Parameters:

Name: 433MHz Universal Remote Control Cloner

Color: Black

Material: Durable ABS Plastic

Working Frequency: 433MHz

Number of Keys: 4 (Multi-function buttons)

Clear Code Buttons: I & II (Dual-button reset)

Battery Type: CR2016

Easy 3-Step Usage Guide

1. Clear Existing Codes (Reset Remote)

Press & hold Button A + B simultaneously for 2 sec (LED flashes 3 times).

Release one button, then quickly press it 3 times (LED flashes rapidly).

Release all buttons → Press any key → If LED turns off, reset is successful.

If LED stays on, repeat the process.

2. Copy Remote Signals (Cloning Mode)

Place original remote and clone remote close together.

Press & hold the same button on both remotes for 2 sec (LED flashes twice).

Release after 1 sec (LED keeps flashing) → Press the button again.

If LED stays on, cloning is successful!

Repeat for other buttons as needed.

3. Restore Lost Codes (Backup Recovery)

If codes are accidentally cleared:

Press Bottom Two Buttons (LED flashes rapidly).

Press any key → LED stays on (codes restored).

Troubleshooting (Partial Button Issues)

If some buttons work but others don’t:

Clear all codes (Step 1).

Re-copy only the failed buttons (Step 2).

Clear codes again (Step 1).

Restore backup (Step 3) → Successfully overwrites faulty keys while keeping working ones.

Repeat until all buttons function.

Key Features:

✔ Universal Compatibility – Works with 433MHz fixed-code garage doors, gates, and access systems.

✔ One-Touch Cloning – Copy up to 4 buttons from existing remotes.

✔ Error Recovery – Restore lost codes easily.

✔ Compact & Durable – Lightweight ABS casing with long-lasting battery.

Note: Only clones fixed-code remotes (not rolling-code systems).

Why Choose This Remote Cloner?

No programming needed – Simple copy-paste functionality.

Quick setup – Ready to use in seconds.

Ideal for: Home garages, electric gates, parking barriers, and more!
